Atmospherics
The Silent Storm Snow Machine
Realistic, Artificial Snow in an Instant!
/ 01
The Silent Storm Snow Machine
From a snow-covered ground to falling snow, the Silent Storm will create a winter wonderland any time of year.
Need the stage scene to go from a quiet, somber evening to a blustery winter storm? Ultratec’s Silent Storm DMX Snow Machine was created with just that in mind.
The Silent Storm, with 2-channel DMX fan speed and flow control, is a remarkable snow machine, flowing 70% more snow output than its predecessor. Realistic, artificial snow in an instant!
With the variable snow output option, snowflake size can easily be adjusted to be big or small. Plus, the variable flow remote control included provides easier control of the machine and scene requirements.
The Silent Storm Snow Machine is available in 110V or 220V.
LIST PRICE
CLS-7100 w/o industrial option
110V: $1,704.98 USD
CLS-7105 w/ industrial option
110V: $1,837.53 USD
CLS-7150 w/o industrial option
220V: $1,704.98 USD
CLS-7155 w/ industrial option
220V: $1,995.68 USD
/ 02
Models and Features
Models - 110 Volt
CLS-7100 Silent Storm DMX Snow Machine 110V (Remote Included)
CLS-7105 Silent Storm DMX Snow M/C 110V w/Ind’l Optn(Remote Included)
Models - 220 Volt, CE Available
CLS-7150 Silent Storm DMX Snow Machine 220V (Remote Included) CE CERTIFIED
CLS-7155 Silent Storm DMX Snow M/C 220V w/ Industrial Option (Remote Included)
Features
- Variable Output, Timer Remote Included
- Hanging Truss Adapter Option is Available
- Built-in 5-Pin DMX control for Fan & Flow Settings
- Powder-coated stainless steel chassis
- 70% More Output than our previous True North Snow Machine
- Variable Snow Output & Flake Size
- Fluid Distribution System (FDS) available
Specifications
- Length: 23 in / 58 cm
- Width: 10 in / 25 cm
- Height: 11 in / 28 cm
- Net Weight: 22 lbs / 10 kgs
- Power Cord: 6 ft – 1.8 m
- Rating: 9 amps AC @ 110 volts @ 60 hz
- Regulatory Compliance: This product has been certified to CSA/UL Standards by QPS Canada Inc.
Shipping Dimensions
Shipping Specifications per Model
| Model | Length | Width | Height | Weight | |
|---|---|---|---|---|---|
| CLS-7155 | Silent Storm DMX Snow M/C 220V w/Indl Optn(Remote Included) | 27 in – 69 cm | 14 in – 36 cm | 12 in – 31 cm | 32 lbs – 15 kgs |
| CLS-7150 | Silent Storm DMX Snow Machine 220V (Remote Included) | 27 in – 69 cm | 14 in – 36 cm | 12 in – 31 cm | 31 lbs – 14 kgs |
| CLS-7105 | Silent Storm DMX Snow M/C 110V w/Ind’l Optn(Remote Included) | 27 in – 69 cm | 14 in – 36 cm | 12 in – 31 cm | 32 lbs – 15 kgs |
| CLS-7100 | Silent Storm DMX Snow Machine 110V (Remote Included) | 27 in – 69 cm | 14 in – 36 cm | 12 in – 31 cm | 31 lbs – 14 kgs |
Output
- Run Time: Continuous
- Fluid Consumption: Continuous – 240 cc/ min.
/ 03
Parts and Service
Service Manual
Service Photos
Parts List
| Product Code | Description | Unit |
| CLF2636 | Truss Bracket | Each |
| CLF2788 | Snow/Versa DMX Truss Bracket Heavy Duty | Each |
| CLS7110 | Silent Storm Remote 5-Pin | Each |
| CXP1117 | Snow Machine Blower 110V w/Mounting Plate | Each |
| CXP1161 | Silent Storm Chassis Base | Each |
| CXP1162 | Silent Storm Lid Only | Each |
| CXP1216 | 1/4 ID Black PVC Industrial Hose | LF |
| CXP1221 | 3/4″ Plastic Strain Relief | Each |
| CXP1272 | #8 x 1/2″ Self Tapping Screws B/O | Each |
| CXP1285 | Snow Machine Blower 220V | Each |
| CXP1288 | 1/4″ Hole Grommet Thin | Each |
| CXP1294 | 8/32 x 3/4 Phillips Pan Head Screw B/O | Each |
| CXP1296 | 8/32 Nylon Locknut | Each |
| CXP1340 | Chip – Silent Storm Main V4.09 5-Pin | Each |
| CXP1345 | Chip – Universal Remote V0.33 5-Pin/RJ | Each |
| CXP2060 | 5/8 S.S. Industrial Hose Clamp | Each |
| CXP2225 | Dry Icer Foam Grip | Each |
| CXP2436 | Machine Feet – Set Of 4 | Each |
| CXP2475 | Heater Triac Board Assembly | Each |
| CXP2476 | 1/4″ Silicone Tube LF | LF |
| CXP3602 | Snow Machine Mini Pump Bracket S/S | Each |
| CXP3607 | Snow Machine/Radiance Pump 110V | Each |
| CXP3610 | Snow Machine Net Nozzle w/O-Ring | Each |
| CXP3611 | Snow Machine 4mm Brass Stone Filter | Each |
| CXP3614 | Snow Machine O-Ring | Each |
| CXP3616 | Snow Machine 4mm Fluid Tube LF | LF |
| CXP3617 | Snow Machine/Radiance Pump 220V | Each |
| CXP4255 | 1/4 Lock Washer | Each |
| CXP4261 | D Plug for 14/3 Cable | Each |
| CXP4263 | Schuko Plug 240V | Each |
| CXP4286 | 1/4″ Flat Washer | Each |
| CXP4290 | Industrial Filter Check Valve | Each |
| CXP4402 | 1/4″ Brass Stone Filter Assembly | Each |
| CXP6040 | 14/3 6´ Power Cord w/3 Prongs | Each |
| CXP7103 | Snow Machine Plastic Nozzle | Each |
| CXP7106 | 9″ x 1/2″ Handle PFI/Snow/Prism | Each |
| CXP7108 | Radiance/Snow Power Switch | Each |
| CXP7110 | Snow Machine Blower Strap | Each |
| CXP7111 | Snow Machine Egg Crate Foam | Each |
| CXP7115 | Silent Storm PCB 110V 5-Pin | Each |
| CXP7115R | Silent Storm PCB 110V 5-Pin RECON. | Each |
| CXP7120 | Silent Storm PCB 110V RJ45 | Each |
| CXP7120R | Silent Storm PCB 110V RJ45 RECON. | Each |
| CXP7125 | Silent Storm PCB 220V 5-Pin | Each |
| CXP7130 | Silent Storm PCB 220V RJ45 | Each |
Looking for a part for your Silent Storm Snow Machine? Contact us.
T: 519.951.3355
TF: 866.534.5557
E: [email protected]
/ 04
Watch the Product Video
/ 05
Fluids
Snow Fluids
It takes more than a well-built snow machine to create a realistic-looking snowfall. The right snow fluid is essential to setting the perfect scene and achieving optimal performance from your snow machine. Using Ultratec’s line of premium snow fluids will ensure you create the desired snow effect, on the queue for any event.
Fluids are available in 4 L, 20 L, and 205 L containers. Not sure which fluid you need to create the desired effect? Container our sales team.
North America
T: 800-388-0617
E: [email protected]
Europe
T: +49 (0)69 87 000 1850
E: [email protected]
True North Snow Fluid
Ultimate Extra Dry Snow Fluid
Northern Snow Fluid
/ 06
Accessories
Silent Storm Snow Machine
The accessories listed here are for the Silent Storm Snow Machine. Looking for an accessory not listed here? Contact our sales team.
North America
T: 800-388-0617
E: [email protected]
Europe
T: +49 (0)69 87 000 1850
E: [email protected]
CLF-2636 Truss Bracket
CLF-6000 Swivel Bracket
CXP-7109 Silent Storm Remote RJ45
CLS-7110 Silent Storm Remote 5-Pin
CLF-2788 Snow-Versa DMX Truss Bracket Heavy Duty
/ 07
